ADW-400

ADW-400

ADW-400 is a so-called thin-walled (dual wall), semi-flexible shrink tubing made of flame-retardant (VW-1) polyolefin with glued inside.mmande (VW-1) polyolefin with glued inside.

The ADW-400 has a shrinkage capacity of 4:1

Upon heating (shrinkage), the adhesive that seals against the object melts and flows and provides 100% waterproof protection. The shrink tubing ADW-400 is suitable for a variety of applications such as sealing cables, wires, joints, branches, components and has very good specifications (MIL, UL etc.).

Standard color: Black

Other colors: On request (roll only). Transparent, White, red, green, yellow, blue, brown, purple, orange etc.

Corresponds to: Tyco / Raychem ATUM / CGAT, DSG-Canusa Deray-IAKT, Hellermann Tyton T42, Sumitube^® W5B11(4X) / Sumitube^® W3B2(4X), Hongshang H-5(4X)-F

Description

Features:
Crosslinked co-extruded adhesive lined Polyolefin • Shrink ratio: 3:1 and 4:1
Flame retardant • Excellent sealing and insulation properties • UV resistant

Approvals:
UL 224 125°C VW-1 600 V file E526134 • CSA C22.2 No. 198.1-06 (except clear)
Meets: SAE-AMS-DTL-23053/4 • Meets: RoHS

Application:
Operating temperature: -55 °C to +125 °C • Minimum shrink temperature: +70 °C
Minimum full recovery temperature: +110 °C • Longitudinal change: 0 ± 10% max.

Order information:
Color: black
Other colors: red, blue, yellow, green, white, clear
Also available in various lengths and in mini boxes
